Precision HC207-22 Wide Inner Ring Insert Bearing | 1-3/8" Bore x 72mm Outer Diameter x 20mm Width (Dual Set Screws | Replaces G1106KRRB, UEL207-106D1, YEL207-106, VE-222, NA207-22, INS-SXR-106)

⚡ Technical Specs & Interchange Directory

• Series Reference: HC207-22 (1-3/8" Bore Profile)

• OEM Cross-Match Part Numbers: G1106KRRB, UEL207-106D1, YEL207-106, VE-222, NA207-22, UG207-22, INS-SXR-106, RA022RR

• Imperial Inner Bore: 1-3/8 Inches (1.375" / 34.925 mm)

• Outer Diameter: 72 mm

• Total Width / Thickness: 20 mm (Extended wide inner ring for enhanced stability)

• Material Composition: High-Carbon GCr15 Chrome Steel

• Locking Technology: Dual Socket Set Screws (Offset configuration for maximum shaft bite)

• Spherical Outer Ring: Compensates for initial angular shaft misalignment

• Seal Design: High-Performance Dual Lip Rubber Seals with Steel Flingers

💡 Key Structural Advantages

• Lock-Tight Shaft Retention: Dual set screws anchor firmly into the shaft when torqued down, eliminating axial drift and rotational play under heavy cyclic loads.

• Balanced Force Distribution: The extended inner ring design widens the contact surface along the shaft, minimizing stress concentration and premature wear.

• Universal Block Drop-In: Engineered to slide effortlessly into standard 207-series pillow blocks, flanged housings, and take-up assemblies with zero modification.

• Deep Environmental Defense: Pre-lubricated with high-grade industrial grease and sealed tightly to repel abrasive dirt, moisture, and agricultural debris.

🚜 Operational Applications

• Agricultural Equipment: Combine harvester components, heavy grain elevators, and tractor implement drivelines.

• Industrial Bulk Handling: Aggregate conveyor systems, heavy-duty sorting rollers, and automated processing lines.

• Mechanical Infrastructure: Industrial blowers, large fan assemblies, and commercial power transmission drives.
