Heavy-Duty 2-Inch SB211-32 Set-Screw Insert Ball Bearing | 2" Bore x 100mm Outer Diameter x 21mm Width (Cross: YAT211-200, YA200RRB-100, FHS211-32, SB211-32, LS-232, AS211-200, L-32)
SB200
Spannlager

Heavy-Duty 2-Inch SB211-32 Set-Screw Insert Ball Bearing | 2" Bore x 100mm Outer Diameter x 21mm Width (Cross: YAT211-200, YA200RRB-100, FHS211-32, SB211-32, LS-232, AS211-200, L-32)

Engineered specifically for high-torque industrial drivelines, large automated material conveyors, and demanding agricultural harvesting machinery, the SB211-32 insert bearing delivers exact 2" x 100mm x 21mm dimensions manufactured from premium GCr15 high-carbon chrome alloy steel. Designed with an extended inner ring and dual heavy-duty set-screws for rock-solid, slip-resistant shaft retention, it functions as a seamless direct OEM drop-in replacement across leading industry standards including SKF YAT211-200, Timken/Fafnir YA200RRB-100, Peer FHS211-32, FYH SB211-32, Browning LS-232, NTN AS211-200, and Seal Master L-32.

Per E-Mail anfragen
✅ ISO-zertifizierte Qualität🚀 Angebot innerhalb von 24 Stunden🌍 Weltweiter Versand

⭐ Engineering Specifications & Global Brand Interchange

  • Series Designation: SB211-32 (2-Inch Precision Imperial Profile)

  • Global OEM Cross-Reference Directory:

    • SKF: YAT211-200

    • Timken / Fafnir: YA200RRB-100 (Featuring 100mm OD variation)

    • Peer: FHS211-32

    • FYH / Asahi: SB211-32

    • Browning: LS-232

    • NTN: AS211-200

    • Seal Master: L-32

  • Imperial Bore (d): 2.000 Inches (50.8 mm)

  • Outer Diameter (D): 100 mm

  • Overall Width (B): 21 mm (Robust heavy-duty cross-section engineered for maximum radial load distribution)

  • Material Composition: GCr15 Premium Bearing-Grade Chrome Steel

  • Locking Configuration: Extended Inner Ring with Twin Heavy-Duty Set-Screws

  • Outer Ring Geometry: Spherical Contour (Self-aligning capability to absorb initial shaft deflection)

  • Sealing Mechanism: Advanced Dual-Lip Contact Seals paired with Protective Steel Slingers

🚗 Performance Highlights & Benefits

  • Slip-Free Clamping: Twin set-screws distribute powerful radial pressure evenly onto drive shafts, preventing rotational slippage during heavy load cycles.

  • Low-Noise Dynamics: Super-finished raceway surfaces minimize internal friction, maintaining stable operating temperatures under continuous high-speed rotation.

  • Universal Housing Integration: Designed for immediate, hassle-free drop-in installation inside standard 211-series pillow blocks, flange units, and take-up assemblies.

  • Enhanced Contamination Defense: Factory pre-greased and tightly sealed to successfully block out moisture, abrasive dust, and fine particulate matter.

⚙️ Target Industrial Applications

  • Material Handling: High-capacity roller conveyors, automated sorting networks, and heavy industrial belt drives.

  • Agricultural Machinery: Combine harvester power take-offs, grain elevators, and heavy tractor drivelines.

  • General Industrial Systems: Large ventilation fans, crushing equipment, and heavy textile machinery.
