HC205-15 Insert Ball Bearing | 15/16" Bore x 52mm OD x 17mm Width with Dual Set Screws (Replaces G1015KRRB, RA025RR)

📋 Technical Specifications & OEM Cross-Reference

• Product Model: HC205-15

• OEM Interchange Part Numbers: G1015KRRB, RA025RR, WPS015GRC, 1015KRRB

• Imperial Bore Size: 15/16 Inch (0.9375" / 23.8125 mm)

• Outer Diameter: 52 mm

• Overall Thickness / Width: 17 mm (Extended wide inner ring profile)

• Material Composition: High-Carbon GCr15 Chrome Steel

• Locking Technology: Dual Socket Set Screws (Offset configuration for maximum shaft clamping bite)

• Ring Geometry: Spherical Outer Surface (Compensates for initial angular offset and structural deflection)

• Sealing Configuration: Heavy-Duty Dual Rubber Contact Seals with Metal Guards

🌟 Key Engineering Highlights

• Slip-Resistant Clamping: The dual set-screw mechanism bites deeply into the shaft upon tightening, eliminating rotational play and axial drift under continuous load cycles.

• Optimized Stability Profile: The widened inner ring evenly distributes radial and tilting loads, shielding the shaft assembly from premature wear and stress fatigue.

• Universal Housing Compatibility: Designed to drop smoothly into standard 205-series pillow blocks, flanged housings, and take-up assemblies without modification.

• Advanced Contaminant Shielding: Factory pre-lubricated with high-performance industrial grease and guarded by double-lip contact seals to block out abrasive dust, dirt, and moisture.

⚙️ Primary Deployment Sectors

• Agricultural Machinery: Grain augers, combine harvester auxiliary drives, and tractor implement rollers.

• Industrial Conveying Systems: Medium-duty roller conveyors, material sorting tables, and automated packaging lines.

• General Mechanical Units: Industrial blowers, fan assemblies, and commercial gear transmission systems.
