SER205-15 Insert Ball Bearing | 15/16" x 52mm x 19mm, Snap Ring & Set Screw for Agricultural & Conveyor Systems
SER205-15
محامل الإدخال

SER205-15 Insert Ball Bearing | 15/16" x 52mm x 19mm, Snap Ring & Set Screw for Agricultural & Conveyor Systems

Designed for demanding drives, the SER205-15 insert bearing features a 15/16" bore, 52mm outer diameter, and 19mm width. Built from durable GCr15 chrome steel with a snap ring and set screw locking mechanism for superior shaft security in agricultural and conveyor systems.

راسلنا عبر البريد
✅ معتمد ISO🚀 عرض سعر خلال 24 ساعة🌍 شحن عالمي

📐 Dimensional & Technical Specs

  • Part Number: SER205-15

  • Bore Diameter (d): 15/16 inch (~23.81 mm)

  • Outer Diameter (D): 52 mm

  • Bearing Width (B): 19 mm (Inner ring width)

  • Material Composition: Premium GCr15 Chrome Steel

  • Locking System: Set Screw combined with a Snap Ring (Circlip) on the outer ring for precise axial location

  • Seal Configuration: Heavy-duty dual rubber contact seals

🌟 Performance & Design Advantages

  • Precision Dimensions: Manufactured to exact tolerances (15/16" x 52 x 19) to ensure a drop-in replacement fit for standard housings.

  • Enhanced Axial Retention: Features an integrated snap ring on the outer ring alongside secure set screws, preventing any shifting under axial loads.

  • Industrial Durability: High-grade chrome steel provides optimal wear resistance, high load capacity, and extended operational lifespan.

  • Sealed & Pre-Lubricated: Factory-packed with high-temperature grease and tightly sealed to keep out dust, moisture, and debris.

🚜 Primary Applications

  • Agricultural Machinery: Combine harvesters, grain elevators, and tractor auxiliary equipment.

  • Material Handling: Powered roller conveyors, packaging lines, and sorting equipment.

  • General Mechanical Drives: Industrial fan assemblies, HVAC units, and custom power transmission builds.
