Premium HC209-27 Insert Ball Bearing | 1-11/16" Bore x 85mm OD x 22mm Width (Dual Set Screws | Replaces G1111KRRB, UEL209-111D1, YEL209-111, VE-227, NA209-27, INS-SXR-111, WPS111GR)
HC200
محامل الإدخال

Premium HC209-27 Insert Ball Bearing | 1-11/16" Bore x 85mm OD x 22mm Width (Dual Set Screws | Replaces G1111KRRB, UEL209-111D1, YEL209-111, VE-227, NA209-27, INS-SXR-111, WPS111GR)

Engineered for reliable shaft anchoring in heavy-duty mechanical drives, the HC209-27 extended inner ring bearing matches exact 1-11/16" x 85mm x 22mm dimensions with top-grade GCr15 chrome steel. Enhanced with dual socket set screws to neutralize shaft slippage, it functions as a seamless direct OEM replacement for G1111KRRB, UEL209-111D1, YEL209-111, VE-227, NA209-27/UG209-27, INS-SXR-111, and WPS111GR under continuous high-load cycles.

راسلنا عبر البريد
✅ معتمد ISO🚀 عرض سعر خلال 24 ساعة🌍 شحن عالمي

📋 Technical Specifications & OEM Directory

  • Product Model: HC209-27 (1-11/16" Bore Variant)

  • OEM Cross-Match Directory: G1111KRRB, UEL209-111D1, YEL209-111, VE-227, NA209-27, UG209-27, INS-SXR-111, WPS111GR, RA027RR

  • Imperial Inner Bore: 1-11/16 Inches (1.6875" / 42.8625 mm)

  • Outer Diameter: 85 mm

  • Overall Width / Thickness: 22 mm (Extended wide inner ring profile)

  • Material Architecture: High-Carbon GCr15 Chrome Steel

  • Locking Technology: Dual Socket Set Screws (Staggered layout for maximum shaft clamping bite)

  • Spherical Outer Contour: Accommodates initial structural angular misalignment smoothly

  • Seal Configuration: Heavy-Duty Double-Lip Rubber Contact Seals with Steel Flingers

🌟 Advanced Performance Highlights

  • Absolute Anti-Slip Retention: Dual set screws anchor deeply into the shaft when torqued down, completely eliminating rotational play and axial drift during heavy cyclic operations.

  • Optimized Load Distribution: The widened inner ring spreads radial and tilting forces evenly along the shaft, reducing localized stress concentration and extending service life.

  • Drop-In Housing Compatibility: Precision-engineered to slide effortlessly into standard 209-series pillow blocks, flanged housings, and take-up assemblies with zero modification.

  • Rigid Environmental Shielding: Factory pre-lubricated with high-temperature industrial grease and tightly guarded by contact seals to block out abrasive dust, moisture, and debris.

⚙️ Primary Operational Sectors

  • Agricultural Equipment: High-capacity combine harvesters, heavy grain augers, and large tractor implement drivelines.

  • Bulk Material Handling: Aggregate conveyor systems, industrial sorting lines, and automated material transfer machinery.

  • Mechanical Infrastructure: Commercial ventilation blowers, fan banks, and general industrial power transmission drives.
