Precision Metric 60mm SB212 Set-Screw Insert Ball Bearing | 60mm Bore x 110mm Outer Diameter x 22mm Width (Interchange: YAT212-60MM, AS212, FHS212, SB212)

⭐ Engineering Specifications & Global Brand Interchange

• Series Designation: SB212 (60mm Heavy-Duty Metric Profile)

• Global OEM Cross-Reference Directory:

  • SKF: YAT212-60MM

  • NTN: AS212

  • Peer: FHS212

  • FYH / Asahi / PTI: SB212

  • Alternative Ref: GE60KRRB

• Metric Bore (d): 60 mm

• Outer Diameter (D): 110 mm

• Overall Width (B): 22 mm (Robust heavy-duty cross-section optimized for maximum radial load support)

• Material Composition: GCr15 Premium Bearing-Grade Chrome Steel

• Locking Configuration: Extended Inner Ring with Twin Heavy-Duty Set-Screws

• Outer Ring Geometry: Spherical Contour (Self-aligning capability to absorb initial shaft misalignment)

• Sealing Mechanism: Advanced Dual-Lip Contact Seals paired with Protective Steel Slingers

🚗 Performance Highlights & Benefits

• Slip-Free Shaft Clamping: Dual set-screws distribute firm, uniform pressure onto drive shafts, preventing rotational slippage during high-torque operation cycles.

• Low-Friction Dynamics: Super-finished raceway surfaces minimize internal friction, maintaining stable operating temperatures under continuous heavy loads.

• Universal Housing Integration: Engineered for immediate, hassle-free drop-in installation inside standard 212-series pillow block housings, flange units, and take-up assemblies.

• Enhanced Contamination Defense: Factory pre-lubricated and tightly sealed to successfully block out moisture, abrasive dust, and fine particulate matter.

⚙️ Target Industrial Applications

• Material Handling: High-capacity roller conveyors, automated sorting networks, and heavy-duty industrial belt drives.

• Agricultural Machinery: Combine harvester power take-offs, grain elevators, and heavy tractor drivelines.

• General Industrial Systems: Large ventilation fans, industrial crushing machinery, and heavy textile processing equipment.
