High-Performance SB206 Set-Screw Insert Ball Bearing | 30mm Bore x 62mm Outer Diameter x 16mm Width (Replaces AS206, FHS206-30MM, SB206KG5, YAE30R6B)

⭐ Technical Specifications & Cross-Reference Directory

• Product Series: SB206 (30mm Standard Metric Bore Profile)

• OEM Interchange Match List: SB206, SB206-30MM, AS206, FHS206-30MM, SB206KG5, YAE30R6B, GE30KRRB

• Metric Bore Diameter (Inner d): 30 mm

• Outer Diameter (Outer D): 62 mm

• Overall Thickness / Width (B): 16 mm (Robust heavy-duty cross-section optimized for superior radial load distribution)

• Alloy Composition: High-Carbon GCr15 Bearing-Grade Chrome Steel

• Locking Mechanism: Integrated Set-Screw Locking Collar for secure, slip-free shaft anchoring

• Outer Ring Contour: Spherical Outer Surface (Compensates smoothly for initial shaft deflection and housing misalignment)

• Sealing Technology: Reinforced Dual-Lip Contact Rubber Seals with Steel Deflector Shields

🚗 Core Engineering Advantages

• Firm Shaft Retention: The precision dual set-screw locking collar ensures tight, slip-free grip on standard 30mm transmission shafts under continuous operational cycles.

• Friction-Optimized Dynamics: Super-finished internal raceways minimize running friction, maintaining stable, lower operating temperatures at high rotational speeds.

• Universal Housing Compatibility: Tailored for seamless drop-in installation into standard 206-series industrial pillow blocks, flange units, and take-up assemblies.

• Advanced Contaminant Defense: Factory pre-lubricated with multi-purpose grease and tightly shielded to block out dust, grit, and moisture infiltration.

⚙️ Typical Operational Sectors

• Material Handling & Conveyance: Heavy-duty roller conveyor lines, automated sorting systems, and heavy belt drive assemblies.

• Agricultural Machinery: Large combine harvesters, grain elevators, and agricultural ventilation blowers.

• Industrial Automation & Power Units: Packaging machinery, textile equipment, and general mechanical power transmission lines.
