Heavy-Duty 1-5/8" SSUC209-26 Solid Stainless Steel Insert Bearing | 1-5/8" Bore x 85mm Outer Diameter x 49.2mm Width | Sanitary Washdown Corrosion-Resistant Unit (Cross: SUC209-26, MUC209-26, FYH UC209-26S6, Timken GY1110KRRB, Dodge INS-SC-110, Browning VS-226)

Engineered for aggressive washdown zones, heavy-duty food and beverage manufacturing lines, and corrosive chemical processing facilities, the SSUC209-26 stainless steel insert bearing delivers superior anti-rust performance backed by precision 1-5/8" x 85mm x 49.2mm dimensions. Fabricated from solid high-grade stainless steel with an extended inner ring and twin locking set-screws, it ensures rock-solid shaft anchoring under heavy dynamic loads while serving as an exact direct replacement for SUC209-26 / SSUC209-26, MUC209-26, FYH UC209-26S6, Timken/Fafnir GY1110KRRB, Dodge INS-SC-110, and Browning VS-226.

راسلنا عبر البريد
✅ معتمد ISO🚀 عرض سعر خلال 24 ساعة🌍 شحن عالمي

⚓ Specification & Global Interchange Hub

  • Model Designation: SSUC209-26 (1-5/8 Inch Heavy-Sanitary Series)

  • Comprehensive Brand Cross-Reference Directory:

    • Universal Industrial Codes: SSUC209-26 / SSUC209-26

    • Cross-Brand Stainless Prefix: MUC209-26

    • FYH Stainless Designation: UC209-26S6

    • Fafnir / Timken (Chrome Steel Geometry Equivalent): GY1110KRRB

    • Dodge Geometry Equivalent: INS-SC-110

    • Browning Geometry Equivalent: VS-226

  • Imperial Bore Dimension (d): 1-5/8 Inches (approx. 41.28 mm)

  • Outer Ring Diameter (D): 85 mm

  • Total Assembly Width (B): 49.2 mm (Extended inner ring optimized for heavy radial-axial load support)

  • Material Architecture: Solid Anti-Corrosive Stainless Steel (Engineered for maximum oxidation and chemical immunity)

🌟 Engineering Architecture & Performance Highlights

  • Twin Set-Screw Clamping System: Positioned securely on the extended inner ring to apply balanced, slip-resistant clamping force, preventing shaft rotation during high-torque startup.

  • Spherical Self-Aligning Contour: Features an outer ring geometry that automatically adjusts to compensate for minor shaft deflections and housing misalignments.

  • Advanced Sanitary Shielding: Equipped with food-grade rubber contact seals combined with stainless steel protective slingers to exclude moisture, cleaning detergents, and solid debris.

  • Certified Factory Grease: Pre-lubricated with high-purity, NSF-compliant food-safe grease for immediate cleanroom and hygienic deployment.

🚚 Target Industrial Application Sectors

  • Food & Beverage Processing: Heavy meat-sorting conveyors, large bottling wheels, and agricultural washing lines.

  • Pharmaceutical & Chemical Machinery: Cleanroom material handling systems, liquid mixing tanks, and metering pumps.

  • Marine & Outdoor Infrastructure: Wastewater treatment agitators, coastal conveyor frames, and dockside handling equipment.
